Мобильная дробилка RUBBLE MASTER RM 100

Mobile impact crusher Rubble Master RM 100

vibrating channel: capacity approx. 3.5 m³, mass approx. 3600 kg, usable feed length 3.5 m, feed width 1.8 m, feed height 3 m;

Drive unit: diesel engine 181 kW, three-phase voltage 200 V, 45 kVA;

Impact crusher: Inlet opening WxH 950 mm x 700 mm, impact circle ø 960 mm, output up to 200 t/h, feed material size max. 800 mm, end grain cubic up to 70 mm, crushed column min. 300 mm - max. 100 mm;

Side discharge belt: belt width 500 mm, discharge height 2.5 m, drive power 2.2 kW/400 V;

Main carrying strap: strap width 1 m, release height 2.9 m, drive power 11 kW/400V;

Crawler chassis: track width 1905 mm, chain width 400 mm;

magnetic separator; dust suppression; screen box;

Transport dimensions: LxWxH 9.50 m x 2.47 m x 3.05 m;

Reference number: 3102
