Харвестер Wheel Harvester - Versatile and Efficient TCi 1165 (2025)

See atspolska.pl/en/item/17972 for more images.

The Versatile and Efficient TCi 1165 Wheel Harvester

Technical specifications:

Brand: TCi

Model/Type: 1165

Year of production: 2025

Mileage: 31h

Engine: TCi FPT N67 (capacity 6.7L, Stage V), 6 cylinder

Maximum power and torque: 282 hp at 2000 rpm, 1160 Nm at 1500 rpm

Fuel tank capacity: 454l

Weight: 22,910 kg (without accessories)

Dimensions: width: 2940 mm, length: 8220 mm (without Curawia), height: 4055 mm

Wheelbase and ground clearance: wheelbase: 4,520 mm, ground clearance: 655 mm

%u017Buraw: H275ER91, reach 9.1 m, maximum warhead weight 1,650 kg

Drive system: wideRANGE, providing smooth transition between speeds and high torque

Additional information:

Powerful engine: This harvester is equipped with a TCi FPT N67 engine producing 210 kW (282 hp) at 2000 rpm, meeting Stage V emissions standards while ensuring low fuel consumption.

Advanced Hydraulic System: Dedicated pumps power the drive, harvester head, Curaw, fan, and cooling system, enabling multiple functions to be performed smoothly and simultaneously.

Buraw ER: ER technology allows for parallel movements without external linkages, resulting in energy savings and reduced maintenance requirements. The harvester provides excellent visibility from the cab to the work area.

Rotating Cab and Curaw: 360-degree continuous rotation increases the machine's operating range, while the built-in rotating manifold eliminates wear on hydraulic hoses.

D7 control system

Remote Systems: RemoteLOG and LogON: These systems enable real-time monitoring of operation, analysis of operational data, and service planning. They allow control of key machine parameters from any location using a computer or

RemoteLOG provides remote access to data on machine status, location, fuel consumption, and operating history. It enables rapid detection of deviations and scheduling of maintenance activities, reducing downtime and improving fleet efficiency. LogON is a local data analysis system that allows operators to read and interpret information directly from the cab. It facilitates real-time assessment of performance, settings, and production and operating time statistics. Both systems operate in full integration with Tigercat software, providing accurate data, better machine control and a higher level of management of the timber harvesting process.

Comfortable Cab: A spacious, ergonomically designed cab with large windows provides excellent visibility and operator comfort. The TCi 1165 harvester is equipped with an automatic cab temperature control system. Specially positioned air vents optimize airflow and window defrosting.

Leveling System: The leveling cabin and Curaw ensure efficiency and comfort on steep slopes. The tilt angle is 18 degrees forward, 24 degrees backward and 18 degrees sideways.

Stability and Maneuverability: Active oscillation balancing improves machine stability, allowing the crane to operate while traveling. WideRANGE drive provides fast working speeds and powerful pulling power.

Does not require any financial contribution.

Machine ready for immediate delivery.

ATS has a video of the machine working

Possibility of viewing and testing 39-450**

Hours: 350

]]>
