XCMG small XD120 Double Drum Vibratory Road Roller в лизинг
Опубликовано: 28д.
Опубликовано: 28д.
Опубликовано: 28д.
China, Xuzhou City, ChinaXD120 dual-drive dual-vibration vibratory road roller features small amplitude, high frequency vibration, big exciting force as well as separate vibration.It is mainly applicable to compaction work on asphalt top layer of newly built pavement and thinner stable soil pavement, and road maintenance work.With compact structure, high flexibility, small blind area, high operating comfort, it is an ideal compaction equipment for municipal maintenance and highway custody.
Content Unit XD120
Operating weight kg 2850
Front axle weight kg 1350
Rear axle weight kg 1500
Static linear load N/cm 110/122
Working speed km/h 0-10
Theoretical gradeability % 30
Minimum turning radius (inside/outside) mm 2500/3700
Minimum Ground Clearance mm 275
Wheelbase mm 1773
Oscillation angle ° ±8
Brakdistance(smooth cement pavement) m <3.4
Vibration frequency Hz 63/67
Nominal amplitude mm 0.5
Excitation force (high/low frequency) kN 36/41
Drum diameter mm 720
Drum width mm 1200
Charge pressure, drive system MPa 2.5
Peak pressure, drive system MPa 38
Peak pressure, vibration system MPa 25
Peak pressure, steering system MPa 16
Model KUBOTA D1703
Type In-line 3-cylinder water-cooled
Rated power kW 25.6
Rated speed r/min 2600
Drive method Hydrostatic closed-loop
Vibration method Hydrostatic open-loop
Service brake Hydraulic
Parking brake Mechanic/hydraulic
Secondary brake Mechanic/hydraulic
Steering system Articulated
Steering control Articulated
